背景

类微博系统，最频繁用到的功能：

A,D,E用户关注B用户。

B用户推送消息。

A,D,E用户接收消息。

A,D,E用户消费消息。涉及消费排序算法。

之前写过一篇《三体高可用PCC大赛 - facebook\微博 like场景 - 数据库设计与性能压测》

LIKE相关场景，用PostgreSQL来设计，性能杠杠的。

本文则是与消息推送、消息消费相关的场景。

以内容2048字为例。

设计

为了满足高效率的推送与消费，设计时，需要考虑到分区。分区后，也便于将来做较为透明的分库。

例如可以按用户的UID进行哈希分区。

1 hash 分区表

创建消息推送表

create table tbl_feed(
  uid int8,   -- 用户ID
  from_uid int8,   -- 被关注用户ID
  ts timestamp,    -- 被关注用户发送该消息的时间
  content text,    -- 被关注用户发送该消息的内容
  status int       -- 消息被当前用户阅读的状态, 0 初始状态， 1 已消费
);

创建partial index，因为消费时，只关心没有被消费的记录。

create index idx_tbl_feed_1 on tbl_feed(uid,ts) where status=0;

创建1024个分区

do language plpgsql $$
declare
begin
  for i in 0..1023 loop
    execute format('create table tbl_feed_%s (like tbl_feed including all , constraint ck_tbl_feed_%s check(abs(mod(uid,1024))=%s)) inherits(tbl_feed)', i, i, i);
  end loop;
end;
$$;

2 写入 UDF

目前RDS PG 10的分区表写入效率和查询效率不是特别理想，为了达到较好的写入效率，建议可以先使用UDF，动态拼接SQL。

create or replace function ins_feed(int8, int8, timestamp, text, int) returns void as $$
declare
  i int := abs(mod($1,1024));  -- 动态拼接表名
begin
  execute format('insert into tbl_feed_%s(uid,from_uid,ts,content,status) values(%s,%s,%L,%L,%s)', i, $1,$2,$3,$4,$5);
end;
$$ language plpgsql strict;

写入性能

假设有20亿用户，随机输入1个用户，并推送一条2048个英文字的消息。

PG 10，单实例，写入 19.5 万行/s，瓶颈主要在写WAL日志的LOCK上。

\set uid random(1,2000000000)
select ins_feed(:uid,:uid+1,now()::timestamp,repeat(md5('a'),64),0);

pgbench -M prepared -n -r -P 1 -f ./test.sql -c 56 -j 56 -T 120

transaction type: ./test.sql
scaling factor: 1
query mode: prepared
number of clients: 56
number of threads: 56
duration: 120 s
number of transactions actually processed: 23464891
latency average = 0.286 ms
latency stddev = 0.486 ms
tps = 195379.681306 (including connections establishing)
tps = 195404.169885 (excluding connections establishing)
statement latencies in milliseconds:
         0.001  \set uid random(1,2000000000)
         0.285  select ins_feed(:uid,:uid+1,now()::timestamp,repeat(md5('a'),64),0);

消费 UDF

目前RDS PG 10的分区表写入效率和查询效率不是特别理想，为了达到较好的写入效率，建议可以先使用UDF，动态拼接SQL。

create or replace function get_feed(int8, int, text) returns setof tbl_feed as $$
declare
  i int := abs(mod($1,1024));   -- 动态拼接表名
begin
return query execute format('with tmp as
(
update tbl_feed_%s set status=1 where ctid = any (array(
  select ctid from tbl_feed_%s where status=0 and uid=%s order by ts limit %s  -- 每次消费N条，按时间先或后消费都可以，都会走索引
))
returning *
)
select * from tmp order by %s',  -- 排序算法可以写成UDF，或参数传入, 本例使用ts排序
i, i, $1, $2, $3
);
end;
$$ language plpgsql strict;

消费例子

postgres=# select * from get_feed(642960384,10,'from_uid');
-[ RECORD 1 ]------------------------------------------------------------------------------------------------
uid      | 642960384
from_uid | 642960385
ts       | 2018-03-05 19:41:40.574568
content  | 0cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc17
9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e
2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b
9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e
2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b
9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e
2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b
9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e
2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b
9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e
2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b
9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e
2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b
9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e
2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b
9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e
2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b
9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e2697726610cc175b9c0f1b6a831c399e
2697726610cc175b9c0f1b6a831c399e269772661
status   | 1

消费性能

为了观察到实际的消费，即每次消费都有至少20条被真实消费掉，这里先生成一批密集的数据再测。

\set uid random(1,4096)
select ins_feed(:uid,:uid+1,now()::timestamp,repeat(md5('a'),64),0);

pgbench -M prepared -n -r -P 1 -f ./test.sql -c 56 -j 56 -T 120

随机输入一个随机用户，每次消费20行。平均每秒消费 2.7 万次。

# \set uid random(1,2000000000)
测试时使用 \set uid random(1,4096)
select * from get_feed(:uid,20,'ts');

pgbench -M prepared -n -r -P 1 -f ./test.sql -c 56 -j 56 -T 45

transaction type: ./test.sql
scaling factor: 1
query mode: prepared
number of clients: 56
number of threads: 56
duration: 45 s
number of transactions actually processed: 1195840
latency average = 2.106 ms
latency stddev = 2.707 ms
tps = 26560.345111 (including connections establishing)
tps = 26572.467067 (excluding connections establishing)
statement latencies in milliseconds:
         0.001  \set uid random(1,4096)
         2.105  select * from get_feed(:uid,20,'ts');
